Thiết bị lưu trữ mạng Lenovo PX4-400D 70CM9003AP
TOTAL CAPACITY NUMBER OF DRIVES ITEM
0TB Diskless EMEA 70CM9000EA
0TB Diskless EMEA 70CM9005EA
4TB (4HD X 1TB) EMEA 70CM9004EA
8TB (4HD X 2TB) EMEA 70CM9001EA
12TB (4HD X 3TB) EMEA 70CM9002EA
16TB (4HD X 4TB) EMEA 70CM9003EA

Thiết bị lưu trữ mạng Lenovo PX4-400D 70CM9002AP
TOTAL CAPACITY NUMBER OF DRIVES ITEM
0TB Diskless EMEA 70CM9000EA
0TB Diskless EMEA 70CM9005EA
4TB (4HD X 1TB) EMEA 70CM9004EA
8TB (4HD X 2TB) EMEA 70CM9001EA
12TB (4HD X 3TB) EMEA 70CM9002EA
16TB (4HD X 4TB) EMEA 70CM9003EA

Thiết bị lưu trữ mạng Lenovo PX4-400D 70CM9001AP
TOTAL CAPACITY NUMBER OF DRIVES ITEM
0TB Diskless EMEA 70CM9000EA
0TB Diskless EMEA 70CM9005EA
4TB (4HD X 1TB) EMEA 70CM9004EA
8TB (4HD X 2TB) EMEA 70CM9001EA
12TB (4HD X 3TB) EMEA 70CM9002EA
16TB (4HD X 4TB) EMEA 70CM9003EA

Thiết bị lưu trữ mạng Lenovo PX4-400D 70CM9000AP
- Description LenovoEMC px4-400d Network Storage
- Form Factor Desktop form factor; supports up to 4 3.5" SATA HDDs (trays included)
- Processor Intel® Atom D2701 Dual Core 2.13GHz
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations o Diskless option - bring your own hard drives
o Storage pools with RAID expansion, migration, and hot spares
o Advanced RAID levels including hot spare
- RAID Support o RAID 0, 1, 10, 5, hot spare
o Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption o Max: 55W
o Min: 35W (drives spun down)
o Peak: 100W for 6s
o Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- iSCSI Support Supports both file and block storage pools, 256 hosts maximum with the following parameters - Block storage pools: 32 LUNs maximum per pool; 128 LUNs maximum per device. File storage pools: 256 LUNs maximum per pool; 256 LUNs maximum per device.
- Ports o 1 USB 3.0
o 4 USB 2.0
o 2 Ethernet
o 1 eSATA
o 1 HDMI Video
- LAN Standards o IEEE 802.3
o IEEE 802.3u
- AC Voltage 100-240 VAC, 50-60Hz
- Acoustic Noise 35.0 dBA maximum
- Temperature, Humidity, and Altitude o Ambient Temp - Operating: 10° to 40° C; Non-Operating: -40° to 60° C
o Temp Gradient - Operating: 12° C per hour
o Humidity (non-condensing) - Operating: 8% to 85% R.H.; Non-Operating: 5% to 95% R.H.
o Max Wet Bulb - Operating: 26.6° C; Non-Operating: 29.4° C
o Altitude - Operating: to 7,500 feet; Non-Operating: to 40,000 feet
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portuguese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements o Available 10/100/1000 Mbps network Ethernet port
o Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
o Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
o PC Users: Microsoft Windows XP / Vista / 7 / 8
o Mac® Users: Mac OS X 10.6 - 10.8
o Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo EMC PX4-300r 70BJ9003WW
LenovoEMC PX4-300r, 1U 4-bay Rackmount NAS, DISKLESS

Thiết bị lưu trữ mạng Lenovo EMC PX12-400r 70BN9004WW
LenovoEMC PX12-400r, 2U 12-bay Rackmount NAS, DISKLESS

Thiết bị lưu trữ mạng Lenovo EMC PX12-400r 70BN9006WW
LenovoEMC PX12-400r, 2U 12-bay Rackmount Server Class NAS, 24TB (12HDx2TB)

Thiết bị lưu trữ mạng Lenovo EMC PX12-400r 70BN9007WW
LenovoEMC PX12-400r, 2U 12-bay Rackmount Server Class NAS, 36TB (12HDx3TB)

Thiết bị lưu trữ mạng Lenovo EMC PX12-400r 70BN9008WW
LenovoEMC PX12-400r, 2U 12-bay Rackmount Server Class NAS, 48TB (12HDx4TB)

Thiết bị lưu trữ mạng Lenovo EMC PX12-450r 70BR9007WW
LenovoEMC PX12-450r, 2U 12-bay Rackmount Server Class NAS, 48TB (12HDx4TB)

Thiết bị lưu trữ mạng Lenovo EMC PX12-450r 70BR9005WW
LenovoEMC PX12-450r, 2U 12-bay Rackmount Server Class NAS, 24TB (12HDx2TB)

Thiết bị lưu trữ mạng Lenovo EMC PX12-450r 70BR9006WW
LenovoEMC PX12-450r, 2U 12-bay Rackmount Server Class NAS, 36TB (12HDx3TB)

Thiết bị lưu trữ mạng Lenovo PX4-400D 70CM9004AP
TOTAL CAPACITY NUMBER OF DRIVES ITEM
16TB 4 x 4TB HDD 4N709019NA
12TB 4 x 3TB HDD 4N709006NA
8TB 4 x 2TB HDD 4N709009NA
4TB 4 x 1TB HDD 4N709008NA
2TB 2 x 1TB HDD 4N709007NA

Thiết bị lưu trữ mạng Lenovo PX2-300D 70BA9002AP 2 bay
- DESCRIPTION LENOVOEMC PX2-300D NETWORK STORAGE
- Form Factor Desktop form factor; supports up to 2 3.5" SATA HDDs (trays included)
- Processor Intel® Atom Dual Core 1.8GHz D525 processor
- Memory 2GB DDR3
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations 2-drive configurations include SATA-II Server-Class 7200rpm hard drives
- RAID Support • RAID 0, 1 (Hot swap in RAID 1)
• JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption • Max: 40W
• Min: 20W (drives spun down)
• Peak: 65W for 1.5s
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- iSCSI Support iSCSI LUNS – up to 256 LUNs
- Ports • 1 USB 3.0 and 2 USB 2.0 ports
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet ports
• 1 VGA port
- LAN Standards • IEEE 802.3
• IEEE 802.3u
- AC Voltage 100-240 VAC, 50-60Hz
- Acoustic Noise 28 dBA maximum
- Temperature, Humidity, and Altitude • Ambient Temp - Operating: 10° to 35° C (50° to 95° F); Non-Operating: -40° to 60° C (50° to 140° F)
• Temp Gradient - Operating: 12° C per hour
• Humidity (non-condensing) - Operating: 8% to 85% R.H.; Non-Operating: 5% to 95% R.H.
• Max Wet Bulb - Operating: 26.6° C; Non-Operating: 29.4° C
• Altitude - Operating: to 7,500 feet; Non-Operating: to 40,000 feet
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portugese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo PX2-300D 70BA9001AP 2 bay
- DESCRIPTION LENOVOEMC PX2-300D NETWORK STORAGE
- Form Factor Desktop form factor; supports up to 2 3.5" SATA HDDs (trays included)
- Processor Intel® Atom Dual Core 1.8GHz D525 processor
- Memory 2GB DDR3
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations 2-drive configurations include SATA-II Server-Class 7200rpm hard drives
- RAID Support • RAID 0, 1 (Hot swap in RAID 1)
• JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption • Max: 40W
• Min: 20W (drives spun down)
• Peak: 65W for 1.5s
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- iSCSI Support iSCSI LUNS – up to 256 LUNs
- Ports • 1 USB 3.0 and 2 USB 2.0 ports
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet ports
• 1 VGA port
- LAN Standards • IEEE 802.3
• IEEE 802.3u
- AC Voltage 100-240 VAC, 50-60Hz
- Acoustic Noise 28 dBA maximum
- Temperature, Humidity, and Altitude • Ambient Temp - Operating: 10° to 35° C (50° to 95° F); Non-Operating: -40° to 60° C (50° to 140° F)
• Temp Gradient - Operating: 12° C per hour
• Humidity (non-condensing) - Operating: 8% to 85% R.H.; Non-Operating: 5% to 95% R.H.
• Max Wet Bulb - Operating: 26.6° C; Non-Operating: 29.4° C
• Altitude - Operating: to 7,500 feet; Non-Operating: to 40,000 feet
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portugese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo PX2-300D 70BA9004AP 2 bay
- DESCRIPTION LENOVOEMC PX2-300D NETWORK STORAGE
- Form Factor Desktop form factor; supports up to 2 3.5" SATA HDDs (trays included)
- Processor Intel® Atom Dual Core 1.8GHz D525 processor
- Memory 2GB DDR3
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations 2-drive configurations include SATA-II Server-Class 7200rpm hard drives
- RAID Support • RAID 0, 1 (Hot swap in RAID 1)
• JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption • Max: 40W
• Min: 20W (drives spun down)
• Peak: 65W for 1.5s
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- iSCSI Support iSCSI LUNS – up to 256 LUNs
- Ports • 1 USB 3.0 and 2 USB 2.0 ports
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet ports
• 1 VGA port
- LAN Standards • IEEE 802.3
• IEEE 802.3u
- AC Voltage 100-240 VAC, 50-60Hz
- Acoustic Noise 28 dBA maximum
- Temperature, Humidity, and Altitude • Ambient Temp - Operating: 10° to 35° C (50° to 95° F); Non-Operating: -40° to 60° C (50° to 140° F)
• Temp Gradient - Operating: 12° C per hour
• Humidity (non-condensing) - Operating: 8% to 85% R.H.; Non-Operating: 5% to 95% R.H.
• Max Wet Bulb - Operating: 26.6° C; Non-Operating: 29.4° C
• Altitude - Operating: to 7,500 feet; Non-Operating: to 40,000 feet
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portugese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo 70B89001AP 4 bay
- DESCRIPTION LENOVO IOMEGA IX4-300D NETWORK STORAGE
- Form Factor Desktop form factor; supports up to 4 3.5" SATA HDDs (trays included)
- Processor Marvell Armada XP 1.3GHz MV78230 processor
- Memory 512MB DDR3
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations 4-drive configurations include hard drives
- RAID Support • RAID 1, 5 (Parity), 10 (Mirroring)
• 0, JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption • Max: 60W
• Min: 20W (drives spun down)
• Peak: 80W for 10ms
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- Ports • 2 USB 2.0 ports; 1 USB 3.0 port
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet port
- LAN Standards • IEEE 802.3
• IEEE 802.3u
- AC Voltage 100-240 VAC
- Acoustic Noise 32 dBA maximum
- Temperature, Humidity, and Altitude Ambient Temp - Operating: 5° to 35° C; Non-Operating: -10° to 60° C
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portuguese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo 70B89000AP 4 bay
DESCRIPTION LENOVO IOMEGA IX4-300D NETWORK STORAGE
Form Factor Desktop form factor; supports up to 4 3.5" SATA HDDs (trays included)
Processor Marvell Armada XP 1.3GHz MV78230 processor
Memory 512MB DDR3
Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
Configurations 4-drive configurations include hard drives
RAID Support • RAID 1, 5 (Parity), 10 (Mirroring)
• 0, JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
Power Consumption • Max: 60W
• Min: 20W (drives spun down)
• Peak: 80W for 10ms
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
Ports • 2 USB 2.0 ports; 1 USB 3.0 port
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet port
LAN Standards • IEEE 802.3
• IEEE 802.3u
AC Voltage 100-240 VAC
Acoustic Noise 32 dBA maximum
Temperature, Humidity, and Altitude Ambient Temp - Operating: 5° to 35° C; Non-Operating: -10° to 60° C
User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portuguese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo 70B89003AP 4 bay
- DESCRIPTION LENOVO IOMEGA IX4-300D NETWORK STORAGE
- Form Factor Desktop form factor; supports up to 4 3.5" SATA HDDs (trays included)
- Processor Marvell Armada XP 1.3GHz MV78230 processor
- Memory 512MB DDR3
- Ethernet 2 10/100/1000 Mbps Ethernet ports (RJ45 connector)
- Configurations 4-drive configurations include hard drives
- RAID Support • RAID 1, 5 (Parity), 10 (Mirroring)
• 0, JBOD mode available
• Note: RAID/storage pool should be the same capacity, speed, and manufacturer. Mixing different types of drives may result in unpredictable behavior.
- Power Consumption • Max: 60W
• Min: 20W (drives spun down)
• Peak: 80W for 10ms
• Note: These values represent a fully loaded device with the highest capacity HDD. Values may differ with other configurations.
- Ports • 2 USB 2.0 ports; 1 USB 3.0 port
• 2 x RJ45 10/100/1000Mbps (GbE) Ethernet port
- LAN Standards • IEEE 802.3
• IEEE 802.3u
- AC Voltage 100-240 VAC
- Acoustic Noise 32 dBA maximum
- Temperature, Humidity, and Altitude Ambient Temp - Operating: 5° to 35° C; Non-Operating: -10° to 60° C
- User Interface Localization User interface localized for English, French, Italian, German, Spanish, Brazilian Portuguese, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese, Arabic, Hebrew, Turkish, Swedish, Dutch, and Polish
- System Requirements • Available 10/100/1000 Mbps network Ethernet port
• Internet Explorer 7, Firefox® 3.x, Chrome 9, Safari 4 or later browser
• Personal cloud and remote access require an internet connection; UPnP™ compatible router or administrative rights to port forward; 2.5 Mbit/s download, 500Kbit/s upload (not compatible with Active Directory or XP 64 bit)
• PC Users: Microsoft Windows XP / Vista / 7 / 8
• Mac® Users: Mac OS X 10.6 - 10.8
• Linux® Users: Redhat Enterprise 6, Ubuntu 11, OpenSUSE 11.4, other compatible Linux versions

Thiết bị lưu trữ mạng Lenovo EMC PX4-300r 70BJ9006WW
LenovoEMC PX4-300r, 1U 4-bay Rackmount Server Class NAS, 4TB (4HDx1TB)

Thiết bị lưu trữ mạng Lenovo EMC PX4-300r 70BJ9007WW
LenovoEMC PX4-300r, 1U 4-bay Rackmount Server Class NAS, 8TB (4HDx2TB)

Thiết bị lưu trữ mạng Lenovo EMC PX4-300r 70BJ9004WW
LenovoEMC PX4-300r, 1U 4-bay Rackmount Server Class NAS, 12TB (4HDx3TB)

Network Video Recorder Lenovo PX2-300d NVR 70BR9004WW
LenovoEMC PX12-450r, 2U 12-bay Rackmount NAS, DISKLESS

Network Video Recorder Lenovo PX2-300d NVR 70CM9006AP
LenovoEMC PX4-400d Server Class NVR, 4-bay Desktop, 8TB (4HD X 2TB), w/ Milestone Arcus 16 Camera Licenses, 1yr SUP

Network Video Recorder Lenovo PX2-300d NVR 70CM9007AP
LenovoEMC PX4-400d Server Class NVR, 4-bay Desktop, 4TB (2HDx2TB), w/ Milestone Arcus 8 Camera Licenses, 1yr SUP

Network Video Recorder Lenovo PX2-300d NVR 70BA9009AP 2bay
LenovoEMC PX2-300d NVR, 2-bay Desktop, 4TB (2HDx2TB), w/ Milestone Arcus 4 camera licenses, 1yr SUP

Ổ cứng Kingston V200+ SVP200S37A/240G
- Hãng sản xuất: Kington
- Interface: SATA III
- Tính năng:
+ Dung lượng: 240GB /
+ Kích thước: 2.5" /
+ Read up to 535MB /
+ Write up to 480MB /
+ Up to 85K IOPS
- Tốc độ nhanh hơn 10 lần so với ổ cứng khác
- Trang bị trình điều khiển LSI® SandForce® được tùy chỉnh dành cho Kingston
- Bảo hành 36 tháng 1 đổi 1 hoặc đổi model cao hơn
